YOKOGAWA UP35A User Manual

17-12
IM 05P02D41-01EN
(ForDetailedmodel)UP35AOptionalsufxcode:/X1
Non-voltage contact Transistor contact
DI11
DI12
DI13
DI14
DI15
COM
Contact rating: 12 V DC, 10 mA or more
301
302
303
304
305
306
DI
DI11
DI12
COM
DI13
DI14
DI15
301
302
303
304
305
306
DI
+5 V
+5 V
+5 V
+5 V
+5 V
Contact rating: 12 V DC, 10 mA or more
+
+
+
+
+
–
(ForStandardmodel)UP32A Sufxcode:Type2=“2”
(ForDetailedmodel)UP35AOptionalsufxcode:/W1
No-voltage contact Transistor contact
DI11
DI12
COM
Contact rating: 12 V DC, 10 mA or more
301
302
303
DI
DI11
DI12
COM
301
302
303
DI
+5 V
+5 V
Contact rating: 12 V DC, 10 mA or more
+
+
–
(ForDetailedmodel)UP35AOptionalsufxcode:/W4
No-voltage contact Transistor contact
DI41
DI42
COM
Contact rating: 12 V DC, 10 mA or more
501
502
503
DI
DI41
DI42
COM
501
502
503
DI
+5 V
+5 V
Contact rating: 12 V DC, 10 mA or more
+
+
–
► Contact input function registration: 12.1 Setting Contact Input Function
17.4 Wiring
