AdditionalContactOutputAccordingtotheSuffixCodes
(ForStandardmodel)UP35ASufxcode:
Type2= “1”
(forDetailedmodel)UP35AOptionalsufx
code: /Y1
(ForDetailedmodel)UP35AOptionalsufx
codes: /Y4
Transistor contact rating: 24 V DC, 50 mA
DO12
DO11
DO13
DO14
DO15
COM
301
302
303
304
305
306
DO
Transistor contact rating: 24 V DC, 50 mA
DO42
DO41
DO43
DO44
DO45
COM
501
502
503
504
505
506
DO
(ForStandardmodel)UP32A Sufxcode:Type
2=“2”
(forDetailedmodel)UP35AOptionalsufx
code: /W1
(forDetailedmodel)UP35AOptionalsufx
code: /W4
Transistor contact rating: 24 V DC, 50 mA
DO12
DO11
COM
304
305
306
DO
Transistor contact rating: 24 V DC, 50 mA
DO42
DO41
COM
504
505
506
DO
► Contactoutputfunctionregistration:12.2SettingContactOutputFunction
17.4 Wiring
