YOKOGAWA UP35A User Manual

18-10
IM 05P02D41-01EN
ProgramPatternSettingMenu(Menu:PROG>PTNO.(=01to02(04whenthe
option“/AP”isspecified.))>SEGNO.(=01to20(40whentheoption“/AP”is
specified.)))
Parameter
symbol
Name
Display
level
Settingrange Initial value
TSP
Final target
setpoint
EASY
0.0 to 100.0% of PV input range (EU)
(Setting range: P.RL to P.RH)
P.RL
TIME
Segment time
setting
EASY
-: Unregistered
0.00 to 999.59 (“hour.minute” or
“minute.second”)
* Setting available for the parameter
SEG.T=TIME.
* Use the parameter TMU to set
the time unit. (Common in the
instrument.)
* If the setting is 0.00, TSP changes
in stepwise after one control period.
-
TM.RT
Segment ramp-
rate setting
EASY
-: Unregistered
Ramp: 0.0 to 100.0% of PV input
range span (EUS) / 1 hour or 1
minute
Soak: 0.00 to 999.59 (“hour.minute” or
“minute.second”)
* Setting available for the parameter
SEG.T=TM.RT.
* Use the parameter TMU to set
the time unit. (Common in the
instrument.)
Per 1 hour: TMU=HH.MM,
Per 1 minute: TMU=MM.SS
* If it is set to 0.0% of the input range
span, or the segment time 0.00,
the program moves to the next
segment after one control period.
-
S.PID
Segment
PID number
selection
EASY
1 to 4
* PID number can be set when the
parameter “ZON = 0.”
1
JC Junction code STD
CONT: Switching for continuation
HOLD: Hold-on switching (the
controller holds the end-of-segment
setpoint when the segment is
completed, to perform control).
LOC: Local-mode switching (the
controller switches to a local
setpoint when the segment is
completed).
W.SW: Wait during switching between
segments.
W.IV: Wait within a segment interval.
W.SL: Segment switching (the
controller switches to a local
setpoint when the segment is
completed after release.) (5 groups)
PLK.1 to PLK.2 (PLK.4 when the
option“/AP”isspecied.):Linkedto
patterns 1 to 2 (4.)
INS.: Allows a segment to be added to
theendofaspeciedsegment.
DEL.:Allowsaspeciedsegmentto
be deleted.
CONT
18.2ListofParameters
