18-24
IM 05P02D41-01EN
OutputSettingMenu(Menu:OUT)(Continuedfrompreviouspage)
Parameter
symbol
Name
Display
level
Settingrange Initial value
RTS
Retransmission
output type of RET
EASY
OFF: Disable
PV1: PV
SP1: SP
OUT1: OUT (Valve opening: 0 to
100 % in Position proportional
control)
LPS: 15 V DC loop power supply
TSP1: Target SP
HOUT1: Heating-side OUT
COUT1: Cooling-side OUT
MV1: Position proportional output
internal computed value)
PV: PV terminals analog input
PV1
RTH
Maximum value
of retransmission
output scale of RET
STD
When RTS = PV1, SP1, TSP1, PV
RTL + 1 digit to 30000
-19999 to RTH - 1 digit
Decimal point position:
When RTS=PV1, SP1, or TSP1,
decimal point position is same
as that of PV input.
When RTS=PV, decimal point
position is same as that of PV
input scale.
100 % of PV
input range
RTL
Minimum value
of retransmission
output scale of RET
STD
0 % of PV
input range
O1RS
Retransmission
output type of OUT
current output
STD Same as RTS OFF
O1RH
Maximum value
of retransmission
output scale of OUT
current output
STD
When O1RS = PV1, SP1, TSP1,
PV
O1RL + 1 digit to 30000
-19999 to O1RH - 1 digit
Decimal point position:
When O1RS=PV1, SP1, or TSP1,
decimal point position is same
as that of PV input.
When O1RS =PV, decimal point
position is same as that of PV
input scale.
-
O1RL
Minimum value
of retransmission
output scale of OUT
current output
STD -
OU.A
OUT current output
range
PRO
4-20: 4 to 20 mA
0-20: 0 to 20 mA
20-4: 20 to 4 mA
20-0: 20 to 0 mA
4-20
RET.A
RET current output
range
PRO 4-20
MAN.T
Manual output
operation type
PRO
Selects how to manipulate the
control output during manual
operation. (Note)
DT.ET: Direct key method
(ThevaluespeciedbytheUpand
Down arrow keys is output as is.)
ST.ET: SET/ENT key method
(Thevaluespeciedonthesetting
displayandconrmedwiththe
SET/ENT key is output.)
DT.ET
Note: When the control type (CNT) is set to ON/OFF control or heating/cooling control, only the
DT.ET setting can be used. On the position proportional type, parameter MAN.T does not
appear.
18.2ListofParameters
