Safety and EMC Standards
• Safety:
Compliant with IEC/EN 61010-1 (CE), IEC/EN 61010-
2-201(CE),IEC/EN61010-2-030(CE),approvedby
CAN/CSAC22.2No.61010-1(CSA),approvedbyUL
61010-1.
Installation category: II
Pollution degree: 2
Measurement category: I (CAT I) (UL, CSA)
O (Other) (CE)
Rated measurement input voltage: Max. 10 V DC
Rated transient overvoltage: 1500 V (
*)
*: This is a reference safety standard value for
measurement category I of CSA/UL 61010-1, and
for measurement category O of IEC/EN 61010-2-
030. This value is not necessarily a guarantee of
instrument performance.
• EMC standards:
Compliant with
CE marking
  EN61326-1ClassA,Table2(Foruseinindustrial
locations),
EN 61326-2-3
*: The instrument continues to operate at a
measurement accuracy of within ±20% of the
range during testing.
EN 55011 Class A, Group 1
EN 61000-3-2 Class A
EN 61000-3-3
EMC Regulatory Arrangement in Australia and New Zealand
EN 55011 Class A, Group 1
• KC marking: Electromagnetic wave interference
prevention standard, electromagnetic wave protection
standard compliance
Construction, Installation, and Wiring
• Dust-proof and drip-proof: IP66 (for front panel) (Not
availableforside-by-sideclosemounting)/NEMA4*
*: Hose-down test only
•Material:Polycarbonate(Flameretardancy:UL94V-0)
• Case color: White (Light gray) or Black (Light
charcoal gray)
• Weight: 0.5 kg or less
• External dimensions (mm):
UP35A: 96 (W) × 96 (H) × 65 (depth from the panel
face)
UP32A: 48 (W) × 96 (H) × 65 (depth from the panel
face)
(Depth except the projection on the rear panel)
•Installation:Directpanelmounting;mountingbracket,
one each for upper and lower mounting
•
Panel cutout dimensions (mm):
UP35A: 92
+0.8/0
(W) × 92
+0.8/0
(H)
UP32A: 45
+0.6/0
(W) × 92
+0.8/0
(H)
• Mountingattitude:Upto30degreesabovethe
horizontal. No downward titling allowed.
• Wiring: M3 screw terminal with square washer (for
signal wiring and power wiring)
PowerSupplySpecicationsandIsolation
• Power supply:
Rated voltage: 100-240 V AC (+10%/-15%), 50/60 Hz
24 V AC/DC (+10%/-15%) (for /DC option)
• Power consumption:
UP35A: 18 VA (DC: 9 VA, AC: 14 VA if /DC option is
specied)
UP32A: 15 VA (DC: 7 VA, AC: 11 VA if /DC option is
specied)
•Databackup:Nonvolatilememory
• Power holdup time: 20 ms (for 100 V AC drive)
• Withstanding voltage
Between primary terminals and secondary terminals:
2300 V AC for 1 minute (UL, CSA)
Between primary terminals and secondary terminals:
3000 V AC for 1 minute (CE)
Between primary terminals: 1500 V AC for 1 minute
Between secondary terminals: 500 V AC for 1 minute
(Primary terminals: Power
*
and relay output
terminals; Secondary terminals: Analog I/O signal
terminals, contact input terminals, communication
terminals and functional grounding terminals.)
*: Power terminals for 24V AC/DC models are the
secondary terminals.
• Insulation resistance: Between power supply
terminalsandagroundingterminal20MΩormoreat
500 V DC
•Isolationspecications
PV (universal ) input terminals
Control relay (contact point c/contact point a x 2) output terminals
PV event-1 relay (contact point a) output terminals
PV event-2 relay (contact point a) output terminals
Time event-1 relay (contact point a) output terminals
Position proportional relay output terminals
Contact input terminals (all)
RS-485 communication terminals
24 V DC loop power supply terminals
Contact output (transistor) terminals
Ethernet communication terminal
PROFIBUS-DP/DeviceNet/CC-Link communication terminals
Current transformer input terminals
Control, retransmission (analog) output terminals
(not isolated between the analog output terminals)
Valve position (feedback) input terminals
Internal
circuits
Power
supply
The circuits divided by lines are insulated mutually.
Environmental Conditions
Normal Operating Conditions:
•Ambienttemperature:-10to50ºC(side-by-sideclose
mounting: -10 to 40 ºC)
 IftheCC-Linkoptionisspecied,0to50°Cfor
UP35A; 0 to 40 °C for UP32A.
(side-by-sidemounting:0to40°CforUP35A/UP32A
with CC-Link option)
•Ambienthumidity:20to90%RH(nocondensation
allowed)
•Magneticeld:400A/morless
•Continuousvibrationat5to9Hz:Halfamplitudeof
1.5 mm or less, 1oct/min for 90 minutes each in the
three axis directions
 Continuousvibrationat9to150Hz:4.9m/s
2
or
less, 1oct/min for 90 minutes each in the three axis
directions
•Short-periodvibration:14.7m/s
2
, 15 seconds or less
• Shock: 98 m/s
2
or less, 11 ms
•Altitude:2000morlessabovesealevel
• Warm-up time: 30 minutes or more after the power is
turned on
• Startup time: Within 10 seconds
*: The LCD (a liquid crystal display) is used for a
display portion of this product. The LCD has a
characteristicthatthedisplayactionbecomes
late at the low temperature. However, the control
function is not affected.
