5-3
IM 05P02D41-01EN
Quick Setting Function
5
SettingExample
Set the following parameters to set to PID control, thermocouple Type K (range: 0.0 to
500.0ºC), and current control output. No need to change the parameters other than the
following parameters.
Set QSM = YES to enter the quick setting mode.
(1) Set CNT = PID.
(2) Set IN = K1.
(3) Set UNIT = C (initial value).
(4) Set RH = 500.0.
(5) Set RL = 0.0.
(6) Set OT = 00.02
SetEXIT=YEStoquitthequicksettingmode.
The Operation Display is shown.
SettingDetails
ControlType
Parameter
symbol
Name
Display
level
Settingrange Menusymbol
CNT Control type EASY
PID: PID control
ONOF: ON/OFF control (1 point of
hysteresis)
ONOF2: ON/OFF control (2 points
of hysteresis)
H/C: Heating/cooling control
CTL
► Controltype:8.2SettingControlType(CNT)
5.1SettingUsingQuickSettingFunction
