Zebra DS6878 Product Reference Guide

A - 8 DS6878 Product Reference Guide
OCR Quiet Zone 695 50 14-14
OCR Bright Illumination 701 Disable 14-15
OCR Template 547 54R 14-16
OCR Check Digit Modulus 688 1 14-25
OCR Check Digit Multiplier 700 121212121212 14-26
OCR Check Digit Validation 694 None 14-27
Inverse OCR 856 Regular 14-32
UPC/EAN
UPC-A 1 Enable 15-8
UPC-E 2 Enable 15-8
UPC-E1 12 Disable 15-9
EAN-8/JAN 8 4 Enable 15-9
EAN-13/JAN 13 3 Enable 15-10
Bookland EAN 83 Disable 15-10
Bookland ISBN Format 576 ISBN-10 15-11
Decode UPC/EAN/JAN Supplementals
(2 and 5 digits)
16 Ignore 15-12
User-Programmable Supplementals
Supplemental 1:
Supplemental 2:
579
580
000
000
15-15
UPC/EAN/JAN Supplemental Redundancy 80 10 15-15
Decode UPC/EAN/JAN Supplemental AIM ID 672 Combined 15-16
Transmit UPC-A Check Digit 40 Enable 15-17
Transmit UPC-E Check Digit 41 Enable 15-18
Transmit UPC-E1 Check Digit 42 Enable 15-18
UPC-A Preamble 34 System Character 15-19
UPC-E Preamble 35 System Character 15-20
UPC-E1 Preamble 36 System Character 15-21
Convert UPC-E to A 37 Disable 15-22
Convert UPC-E1 to A 38 Disable 15-22
EAN-8/JAN-8 Extend 39 Disable 15-23
Table A-1 Standard Default Parameters (Continued)
Parameter
Parameter
Number
Default
Page
Number
1
User selection is required to configure this interface and this is the most common selection.

Zebra DS6878 Specifications

General

Wavelength	655 nm
Scanner type	2D
Yaw reading angle	-60 - 60 °
Decoding standards	1D, 2D, PDF417, PDF417, microPDF417, Composite Codes (CC-A, CC-B, CC-C), U.S. Postnet and Planet, U.K., Japan, Australian, Netherlands KIX code, Royal Mail 4 State Customer, UPU ICS 4 State Postal, USPS 4CB, TL C-39, Aztec (Standard, Inverse), MaxiCode, DataMatrix/ECC 200 (Standard, Inverse), QR Code (Standard, Inverse and Micro)
Tilt reading angle	-360 - 360 °
Input voltage	5 V
Bluetooth	Yes
Dimensions (WxDxH)	69 x 97 x 185 mm
Certification	FCC, RoHS
Product color	Black
International Protection (IP) code	IP43
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Cables included	USB

Weight and Dimensions

Weight	238 g
