5 - 10 MP7000 Scanner Scale Integrator Guide
USB Staging Flash Drive
A staging USB flash drive can be used to:
a. Set up an MP70XX system from a 123Scan generated set of files
b. Perform MP70XX system cloning
and/or
c. Collect MP70XX statistics, usage, and diagnostics data.
A staging flash drive can be created by123Scan and/or from an MP70XX.
• A 123Scan generated staging flash drive can perform device setups from 123Scan to multiple MP70XXs.
• An MP70XX generated staging flash drive can perform the following functions:
a. Device cloning from one MP70XX to multiple MP70XXs.
b. Back up system settings from an MP70XX (the MP70XX parameter settings can be imported into
123Scan).
c. Collect statistics, usage, and diagnostics data (the data can be viewed in 123Scan).
MP70XX Menu Structure for the USB Staging Flash Drive
• Option 1 - Copy an MP70XX
1
configuration to the USB flash drive.
• Copy parameter settings and firmware from the MP70XX
1
to the USB flash drive for cloning to another
device, or viewing in 123Scan.
• When Option 1 is available the 7-segment display shows a 1, and one beep sounds.
• Option 2 - Load a USB flash drive configuration to the MP70XX
1
.
• Load the parameter settings and firmware (if present) from the staging USB flash drive to this MP70XX
1
.
• When Option 2 is available the 7-segment display shows a 2, and two beeps sound.
• Option 3 - Copy statistics, usage, and diagnostics data to the USB flash drive.
• Copy data from the MP70XX onto the USB flash drive (the data can be viewed in 123Scan).
• When Option 3 is available the 7-segment display shows a 3, and three beeps sound.
• Exit without doing anything - Remove USB flash drive from the MP70XX.
1
Auxiliary device settings, like Zebra corded scanners, are copied/loaded if applicable. Auxiliary cordless
scanners are not supported.
See
Loading Cloning Files on page 5-12 for the process steps.
NOTE The MP70XX system configuration settings and firmware are overwritten.

Zebra MP7000 Specifications

General

Type	Built-in bar code reader
Sensor type	CMOS
Scanner type	1D/2D
Linear (1D) barcodes supported	Codabar, Code 128, Code 32, Code 39, Code 93, Discrete 2 of 5, EAN 128, EAN-13, EAN-8, GS1 DataBar, GS1 DataBar Expanded, GS1 DataBar Omnidirectional, GS1 Databar Limited, Interleaved 2 of 5, JAN, MSI, Plessey, Trioptic, UPC-A, UPC-E
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Han Xin, Micro QR Code, MicroPDF417, PDF417, QR Code
Input voltage	90 - 264 V
Input frequency	47 - 63 Hz
Power source type	AC, RS-232, USB
Power consumption (standby)	3 W
Power consumption (typical)	5.5 W
Standard interfaces	RS-232, RS-485, USB
Connectivity technology	Wired
Keys quantity	4 keys
Product color	Black, Stainless steel
LED indicators	Yes
Image formats supported	BMP, JPEG
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	102 mm
Width	292 mm
Height	128 mm
Weight	5700 g
