Zebra MP7000 User Manual

Operating the Scanner 5 - 13
3. The MP70XX identifies the data on the USB flash drive, and the 7-segment display shows a flash drive menu
sequence. The flash drive menu displays three number options for approximately five seconds each. See
MP70XX Menu Structure for the USB Staging Flash Drive on page 5-10 for menu options.
4. When the option you desire displays in the menu, you have five seconds to select the option by pressing the
EAS button (see
EAS Deactivation Button (Sensormatic only) on page 1-7). One, two, or three beeps sound,
depending on the option selected.
5. You have 15 seconds to confirm the selection by pressing the EAS button again. (If the selection is not
confirmed, four fail beeps sound, and the 7-segment display re-scrolls the menu.)
6. After confirmation, the 7-segment display shows a scrolling bar (
_
). This means the device is working. When
the process is complete (time varies) three success beeps (high/low/high), or four failure beeps sound, and the
scrolling bar stops. Removing the staging flash drive at this point sounds the success or failure beeps again
from the last operation performed.
123Scan Staging Flash Drive Configuration
The Flash Drive Wizard option within the 123Scan utility steps a user through the process of generating a USB
staging flash drive with cloning files.
To access the Flash Drive Wizard from any 123Scan screen, click Tools > Staging Flash Drive (MP70XX only) >
Create Staging Flash Drive Files.
Approved USB Flash Drives for the Flash Drive Well
When using the MP70XX flash drive well, located under the MP70XX platter, the USB flash drive must meet the
specifications below to be accessible (easily inserted into, and removed from the well):
• Maximum thickness: .43 in. (11 mm)
• Maximum width: .82 in. (21 mm)
• Minimum length 2.5 in. (63.5 mm).
NOTE The scrolling bar stops whether or not the cloning process succeeded or failed. If the process
failed, try again or contact the System Administrator.
If the staging flash drive is removed prior to completion, a fail occurs (four beeps sound). Premature
removal of the staging flash drive may result in a partial change in the system.

Zebra MP7000 Specifications

General

Type	Built-in bar code reader
Sensor type	CMOS
Scanner type	1D/2D
Linear (1D) barcodes supported	Codabar, Code 128, Code 32, Code 39, Code 93, Discrete 2 of 5, EAN 128, EAN-13, EAN-8, GS1 DataBar, GS1 DataBar Expanded, GS1 DataBar Omnidirectional, GS1 Databar Limited, Interleaved 2 of 5, JAN, MSI, Plessey, Trioptic, UPC-A, UPC-E
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Han Xin, Micro QR Code, MicroPDF417, PDF417, QR Code
Input voltage	90 - 264 V
Input frequency	47 - 63 Hz
Power source type	AC, RS-232, USB
Power consumption (standby)	3 W
Power consumption (typical)	5.5 W
Standard interfaces	RS-232, RS-485, USB
Connectivity technology	Wired
Keys quantity	4 keys
Product color	Black, Stainless steel
LED indicators	Yes
Image formats supported	BMP, JPEG
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	102 mm
Width	292 mm
Height	128 mm
Weight	5700 g
