Zebra MP7000 User Manual

APPENDIX B TECHNICAL
SPECIFICATIONS
Table B-1 MP70XX Technical Specifications
Item Description
Physical Characteristics
Dimensions
Platter Option
Short (no scale available) Length: 13.9 in. (351.0 mm)
Width: 11.5 in. (292.0 mm)
Depth: 4.0 in. (102.0 mm)
Height above platter: 5.1 in. (129.5 mm) max
Medium scanner and scanner/scale Length: 15.7 in. (398.0 mm)
Width: 11.5 in. (292.0 mm)
Depth: 4.0 in. (102.0 mm)
Height above platter: 5.1 in. (129.5 mm) max
Long scanner and scanner/scale Length: 20.0 in. (506.0 mm)
Width: 11.5 in. (292.0 mm)
Depth: 4.0 in. (102.0 mm)
Height above platter: 5.1 in. (129.5 mm) max
Weight
NOTE Weight includes platter, but not cables
or power supply.
Short: 12.1 lb / 5.5 kg
Medium (no scale): 12.6 lb / 5.7 kg
Medium (with scale): 15.7 lb / 7.1 kg
Long (no scale): 14.6 lb / 6.6 kg
Long (with scale): 17.6 lb / 8.0 kg

Zebra MP7000 Specifications

General

Type	Built-in bar code reader
Sensor type	CMOS
Scanner type	1D/2D
Linear (1D) barcodes supported	Codabar, Code 128, Code 32, Code 39, Code 93, Discrete 2 of 5, EAN 128, EAN-13, EAN-8, GS1 DataBar, GS1 DataBar Expanded, GS1 DataBar Omnidirectional, GS1 Databar Limited, Interleaved 2 of 5, JAN, MSI, Plessey, Trioptic, UPC-A, UPC-E
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Han Xin, Micro QR Code, MicroPDF417, PDF417, QR Code
Input voltage	90 - 264 V
Input frequency	47 - 63 Hz
Power source type	AC, RS-232, USB
Power consumption (standby)	3 W
Power consumption (typical)	5.5 W
Standard interfaces	RS-232, RS-485, USB
Connectivity technology	Wired
Keys quantity	4 keys
Product color	Black, Stainless steel
LED indicators	Yes
Image formats supported	BMP, JPEG
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	102 mm
Width	292 mm
Height	128 mm
Weight	5700 g
