Zebra MP7000 - Scale Displays (Some Scanner;Scale Configurations Only)

1 - 10 MP7000 Scanner Scale Integrator Guide
Figure 1-5 Leveling Screws
Scale Displays (Some Scanner/Scale Configurations Only)
Figure 1-6 Single Head Scale Display
NOTE
Leveling screws accessory kit
MX301-SR00004ZZWR is
shipped with every short and
medium model.
Longer leveling screws with a
1 in. (25 mm) extra length are
available for purchase, if
required (accessory kit p/n
MX302-SR00004ZZWR).
290°
NOTE The MX201-SI00WW supports the single interval scale - lbs and kg; the MX201-DI00WW supports the
dual interval scale - lbs and kg.
