B - 2 MP7000 Scanner Scale Integrator Guide
Power
•
12VDC from POS interface cable (USB PowerPlus, RS-232 or RS-485)
•
Power Supply P/N: PWR-BGA12V50W0WW - 100-240V~, 50/60Hz,
2.4A, 12VDC, 4.16A
•
Idle Mode 3.0 W (typical)
•
Active Mode 5.5 (typical), 6.0 W (maximum)
Typical Usage Power = 3.5 W, assuming 18% Active, and 82% Idle
Data Ports
•
One shared POS port for USB / RS-232 / IBM RS-485
•
Three USB peripheral ports
•
Two powered RS-232 peripheral ports
•
Checkpoint interlock port
•
Scale Display port
•
Internal scale port
Scale
•
30 lb. in 0.01 lb. increments/15 kg in 5 g increments
•
Maximum static weight: 300 lb./136 kg
•
Single-cable and dual-cable protocols
•
Compatible with Mettler price computational scales
•
Options:
• Dual-interval Zebra scale
• 0-12 lb. in 0.005 lb increments and 12-30 lb in 0.01 lb increments
• 0-6 kg in 2 g increments and 6-15 kg in 5 g increments
• Single-head and dual head remote scale displays
• Dual heads rotate fully independently for widest viewing angles
on the market
Horizontal Platter
•
Sapphire glass
•
Produce flip-up bar on scale models
User Interface
•
Soft touch capacitive pads (no buttons to break or wear out, no debris
entry)
•
Large two-color LED (feedback for cashiers and self-checkout)
•
Beeper (adjustable volume and beep tones)
•
Four programmable buttons
•
Camera Snapshot (collecting images for various applications)
Imaging Technology
Type Multiple CMOS Array Imager
Table B-1 MP70XX Technical Specifications
Item Description
