Zebra MP7000 User Manual

Maintenance, Troubleshooting, and Error Codes A - 5
U5 Horizontal Right Current Limit warning
U6 Vertical Left Current Limit warning
U8 Vertical Right Current Limit warning
U9 Image Sensor Warning (either)
U10 Vertical Image Sensor warning
U11 Horizontal Image Sensor warning
U16 Sensormatic EAS Offline warning
U17 Host Protocol warning
U18 Left Channel IR (object detection) failure
U25 Right Channel IR (object detection) failure
U27 User Interface (button interface) failure
U29 EAS Communication Error
U30 Center Channel IR (object detection) failure
U31 Indicates that the Sensormatic control box has an internal high voltage fault. The user should
turn off the Sensormatic control box (EAS tags will not be detected or deactivated).
Table A-1 LED Display Error and Warning Codes (Continued)
LED Display Code Error/Warning Indication

Zebra MP7000 Specifications

General

Type	Built-in bar code reader
Sensor type	CMOS
Scanner type	1D/2D
Linear (1D) barcodes supported	Codabar, Code 128, Code 32, Code 39, Code 93, Discrete 2 of 5, EAN 128, EAN-13, EAN-8, GS1 DataBar, GS1 DataBar Expanded, GS1 DataBar Omnidirectional, GS1 Databar Limited, Interleaved 2 of 5, JAN, MSI, Plessey, Trioptic, UPC-A, UPC-E
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Han Xin, Micro QR Code, MicroPDF417, PDF417, QR Code
Input voltage	90 - 264 V
Input frequency	47 - 63 Hz
Power source type	AC, RS-232, USB
Power consumption (standby)	3 W
Power consumption (typical)	5.5 W
Standard interfaces	RS-232, RS-485, USB
Connectivity technology	Wired
Keys quantity	4 keys
Product color	Black, Stainless steel
LED indicators	Yes
Image formats supported	BMP, JPEG
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	102 mm
Width	292 mm
Height	128 mm
Weight	5700 g
