Zebra MP7000 User Manual

C - 2 MP7000 Scanner Scale Integrator Guide
1014 $N CTRL N SO
1015 $O CTRL O SI
1016 $P CTRL P DLE
1017 $Q CTRL Q DC1/XON
1018 $R CTRL R DC2
1019 $S CTRL S DC3/XOFF
1020 $T CTRL T DC4
1021 $U CTRL U NAK
1022 $V CTRL V SYN
1023 $W CTRL W ETB
1024 $X CTRL X CAN
1025 $Y CTRL Y EM
1026 $Z CTRL Z SUB
1027 %A CTRL [ ESC
1028 %B CTRL \ FS
1029 %C CTRL ] GS
1030 %D CTRL 6 RS
1031 %E CTRL - US
1032 Space Space Space
1033 /A ! !
1034 /B “ "
1035 /C # #
1036 /D $ $
1037 /E % %
1038 /F & &
1039 /G ‘ ‘
1040 /H ( (
1041 /I ) )
Table C-1 ASCII Character Set (Continued)
ASCII Value
(Prefix/Suffix Value)
Full ASCII Code 39
Encode Char
Keystroke
ASCII Character
(Applies to RS-232 Only)
1
The keystroke in bold transmits only if you enabled Function Key Mapping (refer to the MP7000
Scanner Scale Barcode Programming Guide). Otherwise, the unbold keystroke transmits.

Zebra MP7000 Specifications

General

Type	Built-in bar code reader
Sensor type	CMOS
Scanner type	1D/2D
Linear (1D) barcodes supported	Codabar, Code 128, Code 32, Code 39, Code 93, Discrete 2 of 5, EAN 128, EAN-13, EAN-8, GS1 DataBar, GS1 DataBar Expanded, GS1 DataBar Omnidirectional, GS1 Databar Limited, Interleaved 2 of 5, JAN, MSI, Plessey, Trioptic, UPC-A, UPC-E
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Han Xin, Micro QR Code, MicroPDF417, PDF417, QR Code
Input voltage	90 - 264 V
Input frequency	47 - 63 Hz
Power source type	AC, RS-232, USB
Power consumption (standby)	3 W
Power consumption (typical)	5.5 W
Standard interfaces	RS-232, RS-485, USB
Connectivity technology	Wired
Keys quantity	4 keys
Product color	Black, Stainless steel
LED indicators	Yes
Image formats supported	BMP, JPEG
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	102 mm
Width	292 mm
Height	128 mm
Weight	5700 g
