2 - 18 MP7000 Scanner Scale Integrator Guide
RS-232 Terminal Specific Parameters (continued)
Table 2-6 RS-232 Terminal Specific Parameters
Parameter Olivetti Omron CUTE
NCR
(Single
Cable
Scale)
Datalogic
Baud Rate 9600 9600 9600 9600 9600
Parity Even None Even Odd Odd
Stop Bit Select One One One One One
ASCII Format 7-Bit 8-Bit 7-Bit 7-Bit 7-Bit
Hardware Handshaking None None None None None
Software Handshaking ACK/NAK None None None None
Serial Response Timeout 9.9 Sec. 9.9 Sec. 9.9 Sec. 9.9 Sec. 9.9 Sec.
RTS Line State Low High High High High
Beep On <BEL> Disable Disable Disable Disable Enable
Transmit Code ID Yes Yes Yes Yes Yes
Data Transmission Format Prefix/Data/Suffix Data/Suffix Prefix/Data/
Suffix
Prefix/
Suffix *
Data/Suffix
Prefix STX (1002) None STX (1002) STX * None
Suffix ETX (1003) CR (1013) CR (1013)
ETX (1003)
ETX * CR (1013)
The CUTE host disables all parameter scanning, including Set Defaults. If you inadvertently select CUTE, scan
Enable Parameter Barcode Scanning (located in the MP7000 Scanner Scale Barcode Programming Guide)
then change the host selection.

Zebra MP7000 Specifications

General

Type	Built-in bar code reader
Sensor type	CMOS
Scanner type	1D/2D
Linear (1D) barcodes supported	Codabar, Code 128, Code 32, Code 39, Code 93, Discrete 2 of 5, EAN 128, EAN-13, EAN-8, GS1 DataBar, GS1 DataBar Expanded, GS1 DataBar Omnidirectional, GS1 Databar Limited, Interleaved 2 of 5, JAN, MSI, Plessey, Trioptic, UPC-A, UPC-E
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Han Xin, Micro QR Code, MicroPDF417, PDF417, QR Code
Input voltage	90 - 264 V
Input frequency	47 - 63 Hz
Power source type	AC, RS-232, USB
Power consumption (standby)	3 W
Power consumption (typical)	5.5 W
Standard interfaces	RS-232, RS-485, USB
Connectivity technology	Wired
Keys quantity	4 keys
Product color	Black, Stainless steel
LED indicators	Yes
Image formats supported	BMP, JPEG
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	102 mm
Width	292 mm
Height	128 mm
Weight	5700 g
