Z8 Microcontrollers
ZiLOG Z8 MCU Product Overview
UM001601-0803 1-3
1.1.2 Product Development Support
The Z8 MCU product line is fully supported with a range of
cross assemblers, C compilers, ICEBOX emulators, single and
gang OTP/EPROM programmers, and software simulators.
The Z86CCP01ZEM low-cost Z8 CCP™ real-time emula-
tor/programmer kit was designed specifically to support all the
products outlined in Table 1-1.
The Z86CCP01ZEM kit comes with:
• Z8 CCP Evaluation Board
• Z8 CCP Power Cable
• ZiLOG Developer’s Studio (ZDS) CD-ROM , Including
Windows-Based
1
GUI Host Software
• 1999 ZiLOG Technical Library
• Z8 CCP User’s Manual
A Z8 CCP Emulator Accessory Kit (Z8CCP00ZAC) is also
available and provides an RS-232 cable and power cable along
with the 28- and 40- pin ZIF sockets and 28- and 40- pin target
connector cables required to emulate/program 28/40 pin devices.
1. Windows is a trademark of the Microsoft Corporation.
Tab le 1-1. ZiLOG General-Purpose Microcontroller Product Family
PRODUCT ROM/RAM
I/0 T/C AN INT WDT POR
V
BO
RC SPEED PIN
IN (MHz) COUNT
Z86C03 512/60 14 1 2 6 F Y Y Y 8 18
Z86E03 512/60 14 1 2 6 F Y N Y 8 18
Z86C04 1K/124 14 2 2 6 F Y Y Y 8 18
Z86E04 1K/124 14 2 2 6 F Y N Y 8 18
Z86C06 1K/124 14 2 2 6 P Y Y Y 12 18
Z86E06 1K/124 14 2 2 6 P Y N Y 12 18
Z86C08 2K/124 14 2 2 6 F Y Y Y 12 18
Z86E08 2K/124 14 2 2 6 F Y N Y 12 18
Z86C30 4K/236 24 2 2 6 P Y Y Y 12 28
Z86E30 4K/236 24 2 2 6 P Y N Y 12 28
Z86C31 2K/124 24 2 2 6 P Y Y Y 8 28
Z86E31 2K/124 24 2 2 6 P Y N Y 8 28
Z86C40 4K/236 32 2 2 6 P Y Y Y 16 40/44
Z86E40 4K/236 32 2 2 6 P Y N Y 16 40/44
Note: Z86Cxx signify ROM devices; 86xx signify EPROM devices; F = fixed; P = programmable
