Z8 Microcontrollers
ZiLOG I/O Ports
UM001601-0803 5-15
Figure 5-19. Port 3 Configuration with Comparator
PIN
P37
0 P34, P37 Standard Output
1 P34, P37 Comparator Output
D0
P37 OUT
PCON
P32
REF (P33)
+
-
PIN
P34
P37 OUT
P32
REF (P33)
+
-
