DATA, FILE AND PROGRAM TRANSFER
Section 7, Page 9 May 2002
ACCESSING ANTENNA CALIBRATE CACHES
For Antenna calibration data, select Option 4, 6 or 8 from the Access Cache Menu. This
accesses the corresponding Antenna Calibration Cache Menu. As with the Board Data
Calibration Caches, you have three options:
View Antenna Calibrations
Output Antenna Calibrations
Input Antenna Calibrations
Unlike Board Calibration data, Antenna Calibrations are NOT written to the Field Data cache.
They must be output from the antenna calibrate cache. See Section 7.6 for outputting data.
Inputting Antenna Calibrations is common method of inputting calibration values into the
receiver's memory. Magnetic antenna calibrations are supplied by Zonge Engineering for
inputting into the GDP-32
II
. See Section 7.7 for instructions.
GDP32II320 Main Menu
Current Freq Domain Cal Remaining:3388KB
1) View RPIP/CSAMT Board cals
2) Output RPIP/CSAMT Board cals
3) Input RPIP/CSAMT Board cals
Press 1 – 3, ESCAPE):
