RPIP PROGRAM
Section 8, Page 9 January 2003
Upon pressing
Enter
, the program acquires four cycles of data for all enabled channels
(unless the
Escape
key is pressed before completion) and the results will look similar to
the following for the real-time displays (while data are being acquired).
Screen Explanation
SEM - Standard Error of the Mean, (in milliradians), calculated after each cycle.
φ
φφ
φ - Average Phase in milliradians.
0207 RPIP0613 11.7 08 Jan 18 13:47:49
Survey D-D Stacks 1
Tx 1 Rx 3 N OUT
.125 Hz 3/ 4 Cycles Tx Curr 1
CH N SEM
φ
GGGA
1 ON 1 0.02 -61.7 000O
2 ON 2 0.01 -39.0 000O
3 OFF
4 OFF
Taking Data
