GDP-32
II
INSTRUCTION MANUAL
May 2002 Section 9, Page 12
Upon pressing
Enter
to save the data (or
Escape
to discard the data), the screen appears as
follows. The only difference in screens is the change in last block number (0095) and the bottom
command line.
0212 TDIP0613 11.7 08 Jan 18 15:08:59
Survey D-D Stacks 1/ 1
Tx 1 Rx 3 N OUT Isys 1v
1 Hz 4/ 4 Cycles Tx Curr 1
CH N Vp M rho GGGA SEM SP
1 ON 1 0.0645 10.0 1629 000O 151.62 -7.14
2 ON 2 0.0687 10.0 6550 000O 146.12 -3.98
3 OFF
4 OFF
CONT-Take data, ESC-Prev Menu
