COMPLEX RESISTIVITY & HACSAMT PROGRAM
Section 10, Page 11 January 2003
Upon pressing
Enter
, the program will acquire four cycles of data for all enabled channels
(unless the
Escape
key is pressed before completion) and the results will look similar to the
following for the real-time displays (while data are being acquired).
SEM. Standard error of the mean, in milliradians, calculated after each cycle, and based
on the average phase.
φ
φφ
φ. Average raw phase in milliradians.
0094 CR 0535 12.3 15 Mar 98 09:05:10
Survey D-D
Tx 1 Rx 3 N OUT
.125 Hz 3/ 4 Cycles Tx Curr 1
CH N/Ant SEM
φ
φφ
φ
GGGA
1 Ref .09 -139.7 005O
2 Ex 1 .10 -140.4 005O
3 Ex 2 .09 -140.9 005O
4 Ex 3 .10 -139.3 005O
5 Ex 4 .09 -140.6 005O
6 Ex 5 .09 -141.7 005O
7 Ex 6 .10 -142.2 005O
8 OFF
Taking data
