GDP-32
II
INSTRUCTION MANUAL
January 2003 Section 10, Page 12
After the selected number of cycles have been acquired (or
Escape
is pressed), the final display
will appear as follows:
MAG. Magnitude of the received signal in volts, with the FFT magnitude calibrate (which
is stored in the CR CALIBRATE cache) removed. The scaling factor "m" after the number
means "millivolts". See the section towards the end of this manual on SCALING for more
information.
3PTφ
φφ
φ. 3-Point decoupled phase in milliradians, (default) for all channels except the Ref
channel, with the FFT phase calibrate (which is stored in the CR CALIBRATE cache)
removed.
rho. Apparent resistivity in ohm-meters.
RAWφ
φφ
φ. By pressing the operator can select to display either raw phase or 3-point
decoupled phase. If the phase column header reads 3PTφ
φφ
φ,
will be RAWφ
φφ
φ. If raw
phase has been selected the phase column header will read RAWφ
φφ
φ and the
selection
will be 3PTφ
φφ
φ.
0094 CR 0535 12.3 15 Mar 98 09:11:15
Survey D-D
Tx 1 Rx 3 N OUT
.125 Hz 3/ 4 Cycles Tx Curr .56
CH N/Ant MAG 3PT
φ
φφ
φ
rho GGGA
1 Ref 72.140m -41.1 0.0 005O
2 Ex 1 72.317m .0 9.488 005O
3 Ex 2 72.164m .0 37.71 005O
4 Ex 3 72.387m .0 94.57 005O
5 Ex 4 72.098m .0 188.4 005O
6 Ex 5 72.353m .0 330.8 005O
7 Ex 6 72.425m .0 529.9 005O
8 OFF
CONTINUE to save, RESET to discard
PREV NEXT Raw
φ
φφ
φ
