COMPLEX RESISTIVITY & HACSAMT PROGRAM
Section 10, Page 15 January 2003
An example of the complete CR data set stored in the data cache follows. For viewing, it is
divided into two or more screens both vertically and horizontally:
NOTES:
1. Channel 1, the reference channel, has had all magnitudes normalized to the fundamental
magnitude, and the phase is the raw decalibrated phase for both the run-time and the
harmonics portion of the data block.
2. The phase recorded for all non-reference channels (channels 2 through 7 in this
example) will be the 3-point decoupled phases in the top part of the data set example, or the
run-time screen, which is the portion that is displayed when not in data cache mode; and will
be the raw decalibrated phases for the bottom part of the display, which is the harmonic
listing.
3. The CR program is the only program that calculates and uses 3-Point decoupled phase
for the run-time screen. The phase information that is stored in the top portion of the data
set is always the 3-point decoupled phase, regardless of what is displayed real-time, and the
raw decalibrated phases are stored with the harmonic data.
SEM's
Block: 0095 Total:0095
SP in millivolts
CR 0535 98-03-15 09:13:17 12.3v D-D 24.7% 32.2 DegC
Tx 1 Rx 3 N OUT Contact resistance in ohms
.125 Hz 4 Cyc Tx Curr .56
1 Re 72.140m -41.1 0.0 005O .09 0.23 .000u
2 Ex 1 72.317m .0 9.488 005O .10 2.96 1.23K
3 Ex 2 72.164m .0 37.71 005O .09 0.12 690.1
4 Ex 3 72.387m .0 94.57 005O .10 -0.56 1.02K
5 Ex 4 72.098m .0 188.4 005O .09 -1.78 2.27K
6 Ex 5 72.353m .0 330.8 005O .09 -3.56 1.17K
7 Ex 6 72.425m .0 529.9 005O .10 -5.92 1.63K
Harmonics 1 3 5 7 9
1 1.0000 -41.1 980.37m -119.4 946.41m -187.5 904.10m -242.7 858.76m -283.2
2 72.316m .0 72.318m .0 72.316m .0 72.312 .0 72.299m .0
3 72.163m .0 72.164m .0 72.164m .0 72.163 .0 72.162m .0
4 72.387m .0 72.388m .0 72.385m .0 72.375 .0 72.384m .0
5 72.098m .0 72.096m .0 72.098m .0 72.089 .0 72.095m .0
6 72.353m .0 72.353m .0 72.349m .0 72.352 .0 72.353m .0
7 72.425m .0 72.423m .0 72.423m .0 72.420 .0 72.423m .0
