CONTROLLED-SOURCE AUDIO FREQUENCY MAGNETOTELLURICS
Section 11, Page 21 May 2002
11.9 SAMPLE DATA BLOCKS
These data were acquired using an RC network and a constant current laboratory transmitter.
The RC network is as follows:
Block 0010 is the program header and is written to the data cache only when the operator goes
between Menu 2 and 3.
Block 0011 is the main data block and is written at the end of each data acquisition cycle, when
Enter
is pressed in answer to the instruction: "CONTINUE to save, ESCAPE to
discard".
0010
CSAM0537 98-03-15 14:51:55 12.6v AMT
OPER 1 TX ID 1 A-SP 100
JOB 89001 LINE 1.0 N SPREAD 1
1DiffAmpNotch+60,3-50,3S/N185Passed1.00192
2DiffAmpNotch+60,3-50,3S/N177Passed0.99835
3DiffAmpNotch+60,3-50,3S/N61Passed0.99921
4DiffAmpNotch+60,3-50,3S/N57Passed1.00329
5DiffAmpNotch+60,3-50,3S/N60Passed0.99876
6DiffAmpNotch+60,3-50,3S/N66Passed0.99586
Front Panel S/N 12, Cal S/N 6, Temp 23.2, Humidity 35.0, EPROM ZMT-32 Z201h
0011
CSAM0537 98-03-15 15:00:11 12.6v AMT
Tx 1 Rx 3 N OUT
32 Hz 16 Cyc Tx Curr 2.10
1Ex 1134.58m -79.6106.8031O .00 2.96 1.23K 1 100
2Hy 1010.297m-1606.91527.3031O .00 0.12 100.8 1 100
3Ex 2133.86m -79.3151.9031O .00-0.56 1.02K 1 100
4Hy 208.5854m-1591.51512.2031O .00 0.15 105.1 1 100
5Ex 3133.43m -79.5120.8031O .00-3.56 1.17K 1 100
6Hy 309.5981m-1606.61527.1031O .00-5.92 99.23 1 100
Grounded E-field dipole
Card status: Passed or failed QC test.
Gain factors for each card
Analog card information
EPROM version
SEM's in mr
SP in mv
External preamplifier
gains
Contact resistance in ohms A-spacing
50 K
50 K
1 uF
