NATURAL SOURCE MAGNETOTELLURICS
Section 13, Page 15 May 2002
FINISHED TAKING DATA
(or
Escape
was pressed):
All function keys are active:
, , , , , at the end of
data acquisition.
Additional explanation of output:
1Ex 1 6.2036u 0.998 16.89M
2Hy 14 0.0851u 1088.6 16.96M
Apparent resistivity
using Ex⋅
⋅⋅
⋅Ex
*
/Hy⋅
⋅⋅
⋅Ex
*
Apparent resistivity
using Ex⋅
⋅⋅
⋅Hy
*
/Hy⋅
⋅⋅
⋅Hy
*
Phase difference (milliradians) between Ex and Hy
Coherency coefficient
Square root of autopower of Hy, (Hy normalized
by the calibration of the magnetic antenna)
Square root of autopower of Ex
Coil #14
Station number
0128 AMT 0538 12.3 15 Mar 98 09:15:22
Survey Vector AMT
Tx 1 Rx 3 N OUT
.0938- 4 5/ 5 Stacks
6 Levels Point Count: 8285/ 8285
CH Sta/Ant MAG CC/
φ
φφ
φ
rho GGGA
1Ex 16.2036u 0.99816.89M444O
2Hy 140.0851u1088.616.96M444O
3Ey 16.1884u 0.99715.40M444O
4Hx 240.0911u1112.215.48M444O
5OFF
6OFF
7OFF
8OFF
CONT-Take data, ESC-Prev Menu
