NATURAL SOURCE MAGNETOTELLURICS
Section 13, Page 21 May 2002
AN EXAMPLE OF TENSOR DATA
AN EXAMPLE OF TENSOR DATA WITH HZ
0120
AMT 0538 98-04-09 16:19:12 12.1v TEN
Tx 1 Rx 3 N 60
32 Hz 32 Bursts 1 Stack
1Ex 16.6429u 0.8966.238023O 32 -0.02 0 32 100
2Hy 341.6298u-404.6 0231O 32 -0.97 0 1 2
3Ey 34.7596u 0.0038.606u031O 32 0.19 0 32 100
4Hx 348.8842u 675.3 0041O 32 -2.74 0 1 4
freq ExMag HyMag xyRho xyPhz xyCC ExEy* ExEy* ExHx* ExHx* ExHy* ExHy*
192 6.6429u 1.6298u 6.238 675.3 0.896 138.4u -106.6u 7.762u -7.922u 10.04u 7.959u
256 6.6429u 1.6298u 21.20 932.9 0.995 0.119 66.12m -66.47u -709.3u 168.8u 273.3u
freq EyMag HxMag yxRho yxPhz yxCC EyHx* EyHx* EyHy* EyHy* HxHy* HxHy*
192 4.7596u 8.8842u 10.64 -2341.4 0.003 2.610u 0.652u -0.195u 2.488u 0.043u 0.151u
256 4.7596u 8.8842u 10.64 -2341.4 0.982 -994.8u -1.423m 657.0u 370.6u
-3.547u 1.732u
Real, Ima
g
Real, Ima
g
0220
AMT 0538 98-05-07 12:54:55 13.2v TEN
OPER 1 TX ID 1 A-SP 100
JOB 1 LINE 1 N SPREAD 1 CL 0.900 HANN Outlier 2.00 ON Remote OFF
1LoPassNotch+60,3-5,9S/N 52Passed1.00069
2LoPassNotch+60,3-5,9S/N 31Passed1.00151
3LoPassNotch+60,3-5,9S/N 53Passed0.99986
4LoPassNotch+60,3-5,9S/N 51Passed1.00055
5LoPassNotch+60,3-5,9S/N 68Passed0.99986
6LoPassNotch+60,3-5,9S/N 36Passed1.00110
7LoPassNotch+60,3-5,9S/N 25Passed0.99890
Front Panel S/N 16, Cal S/N 5, Temp -450.0, Humidity -450.0, EPROM ZMT-32 Z201h
0221
AMT 0538 98-05-07 12:55:29 13.2v TEN
Tx 1 Rx 3 N OUT
128 Hz 129 Bursts 1 Stack
1Ex 1430.33u 0.016164.7u000O 129 0.00 0 1 100
2Hy 1686.04u 575.0 0000O 129 0.00 0 1 2
3Ey 3447.40u 0.0301.337m000O 129 0.00 0 1 100
4Hx 1345.18u1880.2 0000O 129 0.00 0 1 4
5Hz 1367.28u 0.0 0000O 129 0.00 0 1 5
freq ExMag HyMag xyRho xyPhz xyCC ExEy* ExEy* ExHx* ExHx* ExHy* ExHy*
768 430.33u 686.04u 164.7u 575.0 0.016 -0.259 -0.278 27.88m -8.883m 76.89m 51.44m
1024 421.40u 357.52u 62.68u 2741.7 0.003 0.185 0.410 28.77m 6.017m -16.94m 8.706m
freq EyMag HxMag yxRho yxPhz yxCC EyHx* EyHx* EyHy* EyHy* HxHy* HxHy*
768 447.40u 345.18u 1.337m 1880.2 0.030 -20.32m 63.18m -10.59m 72.01m -1.721m 84.78u
1024 361.67u 270.09u 470.6u 2067.5 0.013 -11.99m 24.73m 4.761m 44.74m 33.63u 1.052m
HzHy* HzHy* HzMag
876.6u -6.042m 367.28u
3.479m 49.68u 414.76u
HzHx* HzHx*
5.315m 4.018m
4.123m 636.4u
