NATURAL SOURCE MAGNETOTELLURICS
May 2002 Section 13, Page 22
AN EXAMPLE OF FULL TENSOR DATA WITH REMOTE REFERENCE
0226
AMT 0538 98-05-07 13:02:10 13.2v TEN
OPER 1 TX ID 1 A-SP 100
JOB 1 LINE 1 N SPREAD 1 CL 0.900 HANN Outlier 2.00 ON Remote ON
1LoPassNotch+60,3-5,9S/N 52Passed1.00069
2LoPassNotch+60,3-5,9S/N 31Passed1.00151
3LoPassNotch+60,3-5,9S/N 53Passed0.99986
4LoPassNotch+60,3-5,9S/N 51Passed1.00055
5LoPassNotch+60,3-5,9S/N 68Passed0.99986
6LoPassNotch+60,3-5,9S/N 36Passed1.00110
7LoPassNotch+60,3-5,9S/N 25Passed0.99890
Front Panel S/N 16, Cal S/N 5, Temp -450.0, Humidity -450.0, EPROM ZMT-32 Z201h
0227
AMT 0538 98-05-07 13:02:49 13.1v TEN
Tx 1 Rx 3 N OUT
128 Hz 129 Bursts 1 Stack
1Ex 1347.46u 0.040108.7u000O 129 0.00 0 1 100
2Hy 17.9696m3126.8 0000O 129 0.00 0 1 6
3Ey 3382.29u 0.02367.56m000O 129 0.00 0 1 100
4Hx 1244.27u 115.3 0000O 129 0.00 0 1 7
5Hz 1331.13u 0.0 0000O 129 0.00 0 1 5
6Hx 1334.13u 0.0 0000O 129 0.00 0 1 6
7Hy 1312.26u 0.0 0000O 129 0.00 0 1 7
freq ExMag HyMag xyRho xyPhz xyCC ExEy* ExEy* ExHx* ExHx* ExHy* ExHy*
768 347.46u 7.9696m 108.7u 3126.8 0.040 0.262 -0.265 24.79m 13.08m -52.25m -0.195
1024 429.69u 5.0145m 275.8u -1682.5 0.029 0.433 -0.399 5.689m -12.04m -40.66m -0.404
freq EyMag HxMag yxRho yxPhz yxCC EyHx* EyHx* EyHy* EyHy* HxHy* HxHy*
768 382.29u 244.27u 67.56m 115.3 0.023 13.92m -20.57m 0.699 -0.297 42.74m -20.29m
1024 265.84u 285.41u 2.908m -149.9 0.018 19.80m -6.856m -0.160 -0.590 23.01m -141.2u
HzHy* HzHy* HzMag ExHyr* ExHyr* EyHyr* EyHyr*
14.46m -3.850m 331.13u 57.40m -7.526m 47.09m 11.34m
20.63m -55.57m 317.06u 54.74m -31.39m 2.441m 1.162m
HzHx* HzHx* ExHxr* ExHxr* EyHxr* EyHxr* HxHxr*
2.647m 680.4u 11.73m -14.20m 44.87m 6.687m 4.245m
2.475m -86.54u 69.44m 2.482m 33.96m -16.83m 5.019m
HxHyr* HxHyr* HyHyr* HyHyr* HxrHyr* HxrHyr* HyrHyr*
145.8u 2.695m -81.68m 41.42m 0 0 27.91m
1.382m -1.076m -555.7u 16.11m 0 0 29.58m
HxHxr* HyHxr* HyHxr* HxrHxr*
580.3u 32.16m 19.60m 24.38m
922.0u 20.36m -52.50m 44.66m
