GDP-32
II
INSTRUCTION MANUAL
May 2002 Section 16, Page 12
Figure 16.5(b) - Analog Board, BD183D
BD192 (notch Filters)
J2 Analog Input
U/4 Serial Number PAL
Zonge Bus ConnectorU/2 (A/D)
