MAINTENANCE
Section 17, Page 17 May 2002
Figure 17.3 Jumper Cable connection to an Analog Board
Analog signal cable
(from Analog I/o panel)
Jumper cable
(to Analog boards 3-8)
Jumper cable
(to Analog board & calibrate board)
Analog Signal Connector
Board Connection Clamp
Analog Board 3
Nylon board guides
Cable label
