GDP-32
II
INSTRUCTION MANUAL
October 2003 Section 4, Page 8
7. Press for “Internal”
voltage source.
8. Press
Enter
to select the
default calibrate voltage
(Cal=1.000V).
0151 RPIP0613 11.7 26 Jan 00 20:32:46
Survey D-D
Tx 1Rx 700N 60, 5
1 Hx 16 Cycles Tx Curr 8
1) Internal
2) External
(Press 1 – 2, ESCAPE):
0151 RPIP0613 11.7 26 Jan 00 20:33:14
Survey D-D
Tx 1Rx 700N 60, 5 ICal 1v
1 Hz 16 Cycles Tx Curr 8
Change calibrate voltage or press
CONTINUE to proceed, ESCAPE to abort.
