Solution Volume Display
AEROSET
®
Customer Training Guide 3-19
94858-103 — July 2003
The following table identifies the solutions in screen positions 11 - 13.
These solutions are located on the weight platforms behind the front-
right door and the volume is indicated by the color of the position. The
status is indicated by the following colors:
• Green – The volume is sufficient.
• Red – The volume is insufficient. The approximate volume
remaining in each bottle is:
•I Ref
< 140 mL
•Alk W
< 64 mL
• Acid W < 64 mL
NOTE: Since the indicators for the solutions on the weight
scales do not display remaining volume, it is recommended
that the bottles be checked visually.
Position Definition
11
ICT™ Reference Solution
12
Alkaline Wash Solution
13
Acid Wash Solution
