Abbott Diagnostics Aeroset - Component Replacement Activity

MODULE 11: COMPONENT REPLACEMENT AND TROUBLESHOOTING
11-22 AEROSET
®
Customer Training Guide
94858-103 — July 2003
Component Replacement Activity
Introduction
In this exercise, you are going to remove and replace the sample and
reagent dispense components, and the Reaction area components.
Objective
Upon completion of the Component Replacement Activity, you will be
familiar with:
• Removing and replacing the Sample Probes and Sample Probe
tubing
• Removing and replacing the Reagent Probes and Reagent Probe
tubing
• Removing and replacing the Mixers
• Removing and replacing the Cuvette Pairs
• Removing and replacing the Sample Carousel Tube Bottom Holders
• Removing and replacing the Source Lamp
• Removing and replacing Poppet Valves
Necessary Materials
• AEROSET System Operations Manual
Procedure
The information for the following steps is found in the AEROSET
System Operations Manual.
Refer to Component Replacement in Section 9, Service and
Maintenance of the AEROSET System Operations Manual to perform
the following procedures:
1. Remove and replace one of the Sample Probes.
2. Remove and replace one of the Reagent Probes.
3. Remove and replace one of the Mixers.
4. Remove and replace one of the Cuvette Pairs.
5. Remove and replace one of the Sample Carousel Tube Bottom
Holders.
6. Remove and replace the Source Lamp.
7. Remove and replace Poppet Valves.
