Instrument Tour
AEROSET
®
Customer Training Guide 1-5
94858-103 — July 2003
INSTRUMENT TOUR
Overview
The primary components of the AEROSET System include the
following:
1. System Control Center, including:
• Color Touchscreen Monitor
• Keyboard
• Computer (CPU)
•Printer
• Component Stand (optional)
• GPIB Communication Cable
2. Analyzer, including:
• Sampling/Processing Area
• Front Door Area
• Right-Side Panel Area
• Left-Side Panel Area
• Back Panel Area
Figure 1.1: Primary Components of the AEROSET System
125602
Analyzer
System Control
Center
To Next Page
