MODULE 9: ICT™ UNIT
9-10 AEROSET
®
Customer Training Guide
94858-103 — July 2003
ICT™ UNIT COMPONENT REPLACEMENT
Your instructor will demonstrate the correct removal and replacement
procedures of the ICT™ Module and ICT Probe.
For information about the removal and replacement of the ICT Module
and ICT Probe, refer to Component Replacement in Section 9, Service
and Maintenance of the AEROSET System Operations Manual.
• ICT Unit = Whole assembly
• ICT Module = Electrode Chip
only.
•ICT Probe is not
changed each time
module is changed.
• Take students to an
instrument and show how
the ICT module is installed.
• Will need flathead
screwdriver.
•Caution:
- Not to install module upside
down.
- Not to over-tighten probe and
tubing, thereby twisting the O-
rings and blocking flow.
- Not to over-tighten screw for
cable. Can crack assembly.
NOTE:
Stainless steel probe has a
different holder than the
teflon probe.
