MODULE 8: CONFIGURATION
8-22 AEROSET
®
Customer Training Guide
94858-103 — July 2003
To configure the Host communication:
• Select in the Action Area.
•Select <Config>.
For information about configuration of the on-line communication, refer
to Host Configuration in Section 2, Installation Procedures and Special
Requirements of the AEROSET System Operations Manual.
For further information about the AEROSET System Host Interface
Communications, refer to the AEROSET Host Interface
Specifications.
Host Communication Icon
Transmission
Interval (sec)
The delay time between data messages is defined.
The default setting is 0 seconds. The acceptable interval is
0-99 seconds.
RS-232C Config Allows selection of the Data Bits (L), Stop Bits (S) and
Parity (NP = no parity, EP = even parity, and OP = odd
parity).
The baud rate is also selected. The default settings are 8L-
1S-NP and 9600.
Blue with a slash—the ONLINE CONFIGURATION screen is
configured offline or the Host is not connected
Blue—Host online and connected
Red and black—the Host is online and connected, but temporarily
suspended. To resume communication, select the Host
Communication icon then select <OK>.
Option Description
• Transmission Interval (sec) -
Enters a delay from instrument
for a slow host.
