92 EKI-7710 Series User Manual
4.9.1.3 LLDP Local Device Info
The LLDP Local Device Info page allows you to view information regarding network
devices, providing that the switch has already obtained LLDP information on the
devices.
To access this page, click Management > LLDP > LLDP Local Device Info.
Figure 4.84 Management > LLDP > LLDP Local Device Info
The ensuing table for Local Device Summary settings are informational only: Chas-
sis ID Subtype, Chassis ID, System Name, System Description, Capabilities Sup-
ported, Capabilities Enabled and Port ID Subtype.
The ensuing table for Port Status settings are informational only: Port, Selected
VLAN and Detail (click the radio box and click Detail to displays the details).
4.9.1.4 LLDP Remote Device Info
The LLDP Remote Device Info page allows you to view information about remote
devices, LLDP information must be available on the switch.
To access this page, click Management > LLDP > LLDP Remote Device Info.
Figure 4.85 Management > LLDP > LLDP Remote Device Info
The following table describes the items in the previous figure.
Item Description
Detail Click to display the device details.
Delete Click to delete the selected devices.
Refresh Click to refresh the remote device information list.
