EKI-7710 Series User Manual 115
The following table describes the items in the previous figure.
4.11.3 Upgrade Manager
The Upgrade Manager page allows you to configure a remote TFTP sever or host file
system in order to upload firmware upgrade images or configuration files.
To access this page, click Tools > Upgrade Manager.
Figure 4.117 Tools > Upgrade Manager
The following table describes the items in the previous figure.
4.11.4 Dual Image
The Dual Image page allows you to setup an active and backup partitions for firm-
ware image redundancy.
Item Description
Backup Method Click the drop-down menu to select the backup method: TFTP or
HTTP.
Server IP Enter the IP address of the backup server.
Backup Type Click a type to define the backup method: image: running configura-
tion, startup configuration, flash log, or buffered log.
Image Click the format for the image type: 7710E_2C_1_00_13.bix (Active)
or vmlinux.bix (backup).
Backup Click Backup to backup the settings.
Item Description
Upgrade Method Click the drop-down menu to select the upgrade method: TFTP or
HTTP.
Server IP Enter the IP address of the upgrade server.
File Name Enter the file name of the new firmware version.
Upgrade Type Click a type to define the upgrade method: image, startup configura-
tion, or running configuration.
Image Click the format for the image type: 7710E_2C_1_00_13.bix (Active)
or vmlinux.bix (backup).
Upgrade Click Upgrade to upgrade to the current version.
