Advantech EKI-7710E-2C User Manual

94 EKI-7710 Series User Manual
4.9.2.2 SNMP Community
The SNMP Community page provides configuration options for the community.
SNMP v1 and SNMP v2c use the group name (Community Name) certification. It’s
role is similar to the password function. If SNMP v1 and SNMP v2c are used, you can
go directly from the configuration settings to this page to configure the SNMP com-
munity.
To access this page, click Management > SNMP > SNMP Community.
Figure 4.88 Management > SNMP > SNMP Community
The following table describes the items in the previous figure.
The ensuing table for Community Status settings are informational only: No., Com-
munity Name, Access Right and Delete (click to delete the desired community
name).
4.9.2.3 SNMP User Settings
The SNMP User Settings page allows you to create SNMP groups. The users have
the same level of security and access control permissions as defined by the group
settings.
To access this page, click Management > SNMP > SNMP User Settings.
Figure 4.89 Management > SNMP > SNMP User Settings
Item Description
Community Name Enter a community name (up to 20 characters).
Access Right Click the radio box to specify the access level (read only or read write)
Apply Click Apply to save the values and update the screen.
