EKI-7710 Series User Manual 39
To access this page, click Monitoring > LLDP Statistics.
Figure 4.7 Monitoring > LLDP Statistics
The following table describes the items in the previous figure.
The ensuing table for LLDP Global Statistics settings are informational only: Inser-
tions, Deletions, Drops and Age Outs.
The ensuing table for LLDP Port Statistics settings are informational only: Port, TX
Frames (Total), RX Frames (Total, Discarded and Errors), RX TLVs (Discarded and
Unrecognized) and RX Ageouts (Total).
4.3.6 IGMP Statistics
The IGMP Statistics function displays statistical package information for IP multicast-
ing.
To access this page, click Monitoring > IGMP Statistics.
Figure 4.8 Monitoring > IGMP Statistics
Item Description
Clear Click Clear to reset LLDP Statistics of all the interfaces.
Refresh Click Refresh to update the data on the screen with the present state
of the data in the switch.
