EKI-7710 Series User Manual 79
4.7.6 802.1x
The 802.1x function provides port-based authentication to prevent unauthorized
devices (clients) from gaining access to the network.
4.7.6.1 802.1x Settings
The 802.1x Settings page allows you to set the state (enabled or disabled) for the
selected IP server address, port, accounting port and associated password, including
a reauthentication period.
To access this page, click Security > 802.1x > 802.1x Settings.
Figure 4.65 Security > 802.1x > 802.1x Settings
The following table describes the items in the previous figure.
The ensuing table for 802.1x Information settings are informational only: 802.1x
State, Server IP, Server Port, Accounting Port, Security Key and Reauth Period.
4.7.6.2 802.1x Port Configuration
The 802.1x Port Configuration page allows you to identify the authorization state for a
port by using a MAC or Port authentication base.
Item Description
State Click Enabled or Disabled to set up 802.1x Setting function.
Server IP Enter the IP address of the local server providing authentication func-
tion.
Server Port Enter the port number (1 to 65535) assigned to the listed Server IP.
Accounting Port Enter the port number (1 to 65535) assigned to the listed server IP
configured to provide authorization and authentication for network
access.
Security Key Enter the variable to define the network security key used in authenti-
cation.
Reauth Period Enter the variable in seconds to define the period of time between
authentication attempts.
Apply Click Apply to save the values and update the screen.
