EKI-7710 Series User Manual 105
The following table describes the items in the previous figure.
The ensuing table for Statistics Information settings are informational only: Index,
Port, Drop Events, Octets, Packets, Broadcast, Multicast, Owner and Delete (click to
delete the desired index).
4.9.7.2 RMON History
The RMON History page allows you to configure the display of history entries.
To access this page, click Management > RMON > RMON History.
Figure 4.104 Management > RMON > RMON History
The following table describes the items in the previous figure.
The ensuing table for History Information settings are informational only: Index,
Port, Buckets Requested, Interval, Owner and Delete (click to delete the desired
index).
4.9.7.3 RMON Alarm
The RMON Alarm page allows you to configure RMON statistics group and alarm
groups.
Item Description
Index Enter an entry selection (1 to 65535) to display its statistical informa-
tion.
Port Enter the respective port number for the selected entry.
Owner Enter the name of the owner of the RMON group.
Apply Click Apply to save the values and update the screen.
Item Description
Index Enter the index entry (1 to 65535) to select the number of new history
table entries.
Port Select the specific port switch.
Buckets Requested Enter the specific (1-50) number of samples to store.
Interval Enter value in seconds (1 to 3600) to designate a specific interval time
for the collection of samples.
Owner Enter the name of the owner of the RMON history group.
Apply Click Apply to save the values and update the screen.
