Advantech EKI-7710E-2C User Manual

EKI-7710 Series User Manual 5
The following view applies to EKI-7710E-2CP, EKI-7710E-2CPI, EKI-7710G-2CP
and EKI-7710G-2CPI.
Figure 1.2 Front View
No. Item Description
1
ETH port Fiber ports x 2
2
ETH port RJ45 ports x 2
3
ETH port RJ45 ports with PoE x 8
4
LNK/ACT LED Link activity LED
5
Speed LED
 Orange: 100M
 Green: 1G
6
System LED panel See “System LED Panel (only for EKI-7710E-2CP/EKI-7710E-
2CPI, EKI-7710G-2CP/EKI-7710G-2CPI)” on page 7 for further
details.
7
Reset button Button allows for system soft reset or factory default reset.
8
Console serial port Console cable port to COM port (DB9 male) on computer to
RS232 managed switch (RJ45 female).
10
9
LNK/ACT
12
34
56
78
3
4
12
5
6
PoE
Console
Reset
SYS
R.M.
PWR1
PWR2
Alarm
9
10
78
EKI-7710G
6
1
3
4
5
2
2
1
6
8
7
