Advantech EKI-7710E-2C User Manual

EKI-7710 Series User Manual 9
1.3.3 Top View
The following view applies to EKI-7710E-2C, EKI-7710E-2CI, EKI-7710G-2C and
EKI-7710G-2CI.
Figure 1.6 Top View
The following view applies to EKI-7710E-2CP, EKI-7710E-2CPI, EKI-7710G-2CP
and EKI-7710G-2CPI.
Figure 1.7 Top View
No. Item Description
1
Ground terminal Screw terminal used to ground chassis
2
Terminal block Connect cabling for power and alarm wiring
No. Item Description
1
Ground terminal Screw terminal used to ground chassis
2
Terminal block Connect cabling for power and alarm wiring
V2+V2-
PWR2 PWR1P-Fail
V1+V1- DC12-48V
1A@24V
1 2
V2+V2-
PWR2 PWR1P-Fail
V1+V1- DC24-48V
1A@24V
1 2
