EKI-7710 Series User Manual 117
The ensuing table for Local Users settings are informational only: User Name, Pass-
word Type, Privilege Type and Delete (click to delete the desired user account).
4.11.7 Reset System
To access this page, click Tools > Reset System.
Click Restore to have all configuration parameters reset to their factory default val-
ues. All changes that have been made will be lost, even if you have issued a save.
Reset settings take effect after a system reboot.
4.11.8 Reboot Device
To access this page, click Tools > Reboot Device.
Click Reboot to reboot the switch. Any configuration changes you have made since
the last time you issued a save will be lost.
4.12 Modbus/TCP Mapping
The data map addresses of Advantech switches shown in the following table start
from Modbus address 30001 for function code 4.
In the given example, the address offset 0x1000 (hex) equals Modbus address
34097, while the address offset 0x1100 (hex) equals Modbus address 34353.
The information given by the Advantech is shown in hex mode.
4.12.1 Modbus/TCP Mapping Table
Privilege Type Click the drop-down menu to designate privilege authority for the user
entry: Admin or User.
Apply Click Apply to create a new user account.
Item Description
Catelog Name Data Type Interpretation Address
Offset (Hex)
Address
3X
Description
System Info Vendor ID =
0x‘13FE
1 word 16 bits HEX 0x0000 30001 Vendor ID = 0x13FE
Unit ID = 0xFF 1 word 16 bits HEX 0x0001 30002 Unit ID = 0xFF
Product Code 1 word 16 bits HEX 0x0002 30003 Product Code
