EKI-7710 Series User Manual 71
4.6.3 Dynamic Forwarding Table
The Dynamic Forwarding function allows you to configure an address tables, which
contain the following:
l The port each hardware address is associated with
l The VLAN to show or clear dynamic MAC entries
l The MAC address selection
To access this page, click MAC Address Table > Dynamic Forwarding Table.
Figure 4.54 MAC Address Table > Dynamic Forwarding Table
The following table describes the items in the previous figure.
The ensuing table for MAC Address Information settings are informational only:
MAC Address, VLAN, Type, Port and Add to Static MAC (click to add the MAC
address to static MAC address list).
4.7 Security
The Security function allows for the configuration of Storm Control, Port Security, Pro-
tected Ports, DoS Prevention, Applications, 802.1x, and IP Security.
4.7.1 Storm Control
The Storm Control page allows you to setup the units and Preamble/IFG to manage
the occurrence of packet flooding on the LAN and consequent traffic to prevent the
degrading of network performance.
Item Description
Port Click the drop-down menu to select the port number to show or clear
dynamic MAC entries. If a port, VLAN or MAC address is not selected
the whole dynamic MAC table is displayed or cleared.
VLAN Click the drop-down menu to select the VLAN to show or clear
dynamic MAC entries.
MAC Address Enter the MAC address to show or clear dynamic MAC entries. If a
port, VLAN or MAC address is not selected the whole dynamic MAC
table is displayed or cleared.
View Click View to display the MAC address information.
Clear Click Clear to clear the MAC Address Information table.
