112 EKI-7710 Series User Manual
4.10.4.3 System Log Server
The System Log Server page allows you to configure the log server.
To access this page, click Diagnostics > System Log > System Log Server.
Figure 4.112 Diagnostics > System Log > System Log Server
The following table describes the items in the previous figure.
The ensuing table for Remote Logging Setting Status settings are informational
only: Status, Server Info, Severity, Facility and Delete (click to delete the desired
server address).
4.10.5 DDM
The DDM page allows you to setup the diagnostic alarm status.
To access this page, click Diagnostics > DDM.
Figure 4.113 Diagnostics > DDM
Item Description
Server Address Enter the IP address of the log server.
Server Port Enter the Udp port number of the log server.
Severity Click the drop-down menu to select the severity level for local log
messages. The default is emerg.
The level options are:
 emerg: Indicates system is unusable. It is the highest level of
severity
 alert: Indicates action must be taken immediately
 crit: Indicates critical conditions
 error: Indicates error conditions
 warning: Indicates warning conditions
 notice: Indicates normal but significant conditions
 info: Indicates informational messages
 debug: Indicates debug-level messages
Facility Click the drop-down menu to select facility to which the message
refers.
Apply Click Apply to save the values and update the screen.
