Advantech EKI-7710E-2C User Manual

2 EKI-7710 Series User Manual
1.1 Supported Models
Standard Models:
Wide Temperature Models:
1.2 Specifications
EKI-7710E-2C EKI-7710G-2C EKI-7710E-2CP
EKI-7710G-2CP
EKI-7710E-2CI EKI-7710G-2CI EKI-7710E-2CPI
EKI-7710G-2CPI
Specifications Description
Interface I/O Port 8 x RJ45 + 2 x Combo (RJ45/Fiber)
Power Connector 6-pin removable screw terminal (power & relay)
Physical Enclosure Metal Shell
Protection Class IP30
Installation DIN-Rail and Wall mount
Dimensions
(W x H x D)
74 x 152 x 105mm
LED Display System LED SYS, R.M, PWR1, PWR2, Alarm
Port LED Speed, Link, Activity
Environment Operating Tem-
perature
Standard Temperature: -10°C ~ 60°C (14°F ~ 140°F)
Wide Temperature: -40°C ~ 75°C (-40°F ~ 167°F)
Storage Tempera-
ture
-40°C ~ 85°C (-40°F ~ 185°F)
Ambient Relative
Humidity
10 ~ 95% (non-condensing)
Switch Properties MAC Address 8K-entry
Switching Band-
width
 EKI-7710E-2C/EKI-7710E-2CI: 5.6 Gbps
 EKI-7710E-2CP/EKI-7710E-2CPI: 5.6 Gbps
 EKI-7710G-2C/EKI-7710G-2CI: 20 Gbps
 EKI-7710G-2CP/EKI-7710G-2CPI: 20 Gbps
Power Power
Consumption
12.1 W@48Vdc (System)
Power Input
 EKI-7710E-2C/EKI-7710E-2CI: 12V~48V (8.4V
to 62.4V)
 EKI-7710E-2CP/EKI-7710E-2CPI: 24V~48V
(16.8V to 62.4V)
 EKI-7710G-2C/EKI-7710G-2CI: 12V~48V (8.4V
to 62.4V)
 EKI-7710G-2CP/EKI-7710G-2CPI: 24V~48V
(16.8V to 62.4V)
