36 EKI-7710 Series User Manual
The following table describes the items in the previous figure.
4.3.2 Logging Message
The Logging Message Filter page allows you to enable the display of logging mes-
sage filter.
To access this page, click Monitoring > Logging Message.
Figure 4.4 Monitoring > Logging Message
The following table describes the items in the previous figure.
Item Description
System Name Click Switch to enter the system name: up to 128 alphanumeric char-
acters (default is Switch).
System Location Click Default to enter the location: up to 256 alphanumeric characters
(default is Default).
System Contact Click Default to enter the contact person: up to 128 alphanumeric
characters (default is Default).
MAC Address Displays the MAC address of the switch.
IP Address Displays the assigned IP address of the switch.
Subnet Mask Displays the assigned subnet mask of the switch.
Gateway Displays the assigned gateway of the switch.
Loader Version Displays the current loader version of the switch.
Loader Date Displays the current loader build date of the switch.
Firmware Version Displays the current firmware version of the switch.
Firmware Date Displays the current firmware build date of the switch.
System Object ID Displays the base object ID of the switch.
System Up Time Displays the time since the last switch reboot.
Item Description
Target Click the drop-down menu to select a target to store the log mes-
sages.
Buffered: Store log messages in RAM. All log messages are
cleared after system reboot.
File: Store log messages in a file.
