EKI-7710 Series User Manual 123
Port Info Port 26 Flow
Control
1 word 16 bits HEX 0x1219 34634
Port 27 Flow
Control
1 word 16 bits HEX 0x121A 34635
Port 28 Flow
Control
1 word 16 bits HEX 0x121B 34636
Port 29 Flow
Control
1 word 16 bits HEX 0x121C 34637
Port 30 Flow
Control
1 word 16 bits HEX 0x121D 34638
Port 31 Flow
Control
1 word 16 bits HEX 0x121E 34639
Port 32 Flow
Control
1 word 16 bits HEX 0x121F 34640
Port Descrip-
tion
20
words
40
chars
ASCII 0x1400 ~
0x166C
35121 ~
35741
Port Description
Port Description =
"100RX,RJ45."
Word 0 Hi byte = '1'
Word 0 Lo byte = '0'
Word 1Hi byte = '0'
Word 1 Lo byte = ‘R’
Word 2 Hi byte = 'X'
Word 2 Lo byte = ‘,’
Word 3 Hi byte = 'R'
Word 3 Lo byte = ‘J’
Word 4 Hi byte = ‘4’
Word 4 Lo byte = ‘5’
Word 5 Hi byte = ‘.’
Word 5 Lo byte = ‘\0’
Port 1
Description
20
words
40
chars
ASCII 0x1400 35121
Port 2
Description
20
words
40
chars
ASCII 0x1414 35141
Port 3
Description
20
words
40
chars
ASCII 0x1428 35161
Port 4
Description
20
words
40
chars
ASCII 0x143C 35181
Port 5
Description
20
words
40
chars
ASCII 0x1450 35201
Catelog Name Data Type Interpretation Address
Offset (Hex)
Address
3X
Description
