130 EKI-7710 Series User Manual
Port Info Port 24 PoE
Current
1 word 16 bits HEX 0x1837 36200
Port 25 PoE
Current
1 word 16 bits HEX 0x1838 36201
Port 26 PoE
Current
1 word 16 bits HEX 0x1839 36202
Port 27 PoE
Current
1 word 16 bits HEX 0x183A 36203
Port 28 PoE
Current
1 word 16 bits HEX 0x183B 36204
Port 29 PoE
Current
1 word 16 bits HEX 0x183C 36205
Port 30 PoE
Current
1 word 16 bits HEX 0x183D 36206
Port 31 PoE
Current
1 word 16 bits HEX 0x183E 36207
Port 32 PoE
Current
1 word 16 bits HEX 0x183F 36208
PoE Power 1 word 16 bits HEX 0x1840 ~
0x185F
36209 ~
36240
PoE Power (W)
Ex: poe power = 10
Received MODBUS
response: 0x000A
Port 1 PoE
Power
1 word 16 bits HEX 0x1840 36209
Port 2 PoE
Power
1 word 16 bits HEX 0x1841 36210
Port 3 PoE
Power
1 word 16 bits HEX 0x1842 36211
Port 4 PoE
Power
1 word 16 bits HEX 0x1843 36212
Port 5 PoE
Power
1 word 16 bits HEX 0x1844 36213
Port 6 PoE
Power
1 word 16 bits HEX 0x1845 36214
Port 7 PoE
Power
1 word 16 bits HEX 0x1846 36215
Port 8 PoE
Power
1 word 16 bits HEX 0x1847 36216
Port 9 PoE
Power
1 word 16 bits HEX 0x1848 36217
Catelog Name Data Type Interpretation Address
Offset (Hex)
Address
3X
Description
